NUMERICAL DESIGNATION: 2.0966 Material designation: CuAl10Ni; CuAl10Ni5Fe4 Bronze Bearing Parts & Slide Plate
Finding copper bushing materials and property data at bronzelube.com, CuAl10Ni5Fe4. Aluminium bronze bushing. Extruded rods. Nominal composition: … CuAl10Ni5Fe4. 2.0966. Bronze with graphite plate, CuAl10Ni5Fe4 graphite bronze bushing, CuAl10Ni5Fe4 slide plate.
Online Material Guide
High Thermal Conductivity: Copper effectively dissipates heat, preventing overheating in machinery. C63000 Nickel Aluminum Bronze Bushing Parts
professional bronze Bushing Supplier
Natural Anti-Friction Properties: This ensures smooth operation and reduces wear between moving parts. C63000 – CuAl10Ni5Fe4 – Nickel Aluminum Bronze Slide Plate
Bronze Parts Material c63000 bronze Focus
Malleability: Copper can be easily shaped, allowing for custom designs and fits. CuAl10Ni5Fe4, C63000 bronze graphite manufacturer, and material parts deign
Why Choose Copper for Bearings?
Corrosion Resistance: Copper’s resistance to corrosion ensures longevity, especially in challenging environments. Material Design!
c63000, aluminium bronze Graphite bearing
Bronze Bushing, Cual10ni5fe4， High Quality Copper Bushing With Competitive Price, Custom manufacturer of bushings made from steel and bronze. Capabilities include broaching, parting, cutting, facing, turning, threading, internal forming, knurling, boring, broaching, drilling, counterboring, countersinking, pocketing, profiling, reaming, tapping and milling. Secondary services include assembly, bending, threading, pressing, welding, plating, passivating, etching, heat treating, anodizing and insert plastic molding. Various industries served include agricultural, architectural, chemical, electronic, marine, medical, military and pharmaceutical. Fast delivery available.
Copper Bushing Bearings: Delving into Their Features, Benefits： DIN 17665 W Nr 2.0966, c63000 nickel aluminum bronze Barts suppliers
Manufacturer of standard and custom thick walled bearing bushings made from solid bronze alloy and cast bronze bearing. Available in customized copper bearing bushing. Features vary depending upon model, including, oil groove type, graphite inserts, grease reservoirs, self-lubricating, lead-free, grooves and flange bronze bushes. Bushings are shock, impact, wear and corrosion resistant. Serves the agriculture, automotive, construction, energy, fluid power, oil and gas, primary metal, railway and recreational industries. Meets the standards material. REACH and RoHS compliant.
“Customized High Quality Copper Bronze Bushing Material.” C63000 nickel aluminum bronze suppliers, Bearing Shop Online, Welcome to bronzelube.com. Nickel Aluminium Bronze Bushing, Nominal Composition CuAl10Ni5Fe4 Bronze Bearing Slide Parts, aluminum bronze c63000 with graphite slide bushing bearings.
taxation planning
Eiusmod tempor incididunt ipsum ut labore dolore magna aliqua. Ut enim minim veniam duisy ipsum sed quis.
Your specialist for Bronze bushing for quality, service and innovation.
Discover the unique properties and advantages of copper bushing bearings, understanding their primary applications and essential care guidelines.
Copper bushing bearings, crafted predominantly from copper, are revered for their exceptional conductivity, corrosion resistance, and natural anti-friction properties. They serve as a pivotal component in various mechanical systems, ensuring smooth, efficient movement between parts.
Aluminium Bronze CuAl10Ni5Fe4 (AlBz10Ni,AlBz10Ni5,CuAl10Ni).This is one of the most popular alloys in this family on a world basis. The unique combination of high mechanical and fatigue strength coupled with excellent wear resistance and non-galling properties combined with good corrosion resistance allows its use over a wide spectrum of applications.
Bronze Bushing Application, Huge small business savings start here Save up to 40% on select our bronze parts
Choose Your Correct Bronze Bearing For Your Machinery. Maintenance Free! Longer Copper Bushing Life! The bronze bearings is widely used in continuous casting rolling machine, mining machinery, shipping machinery, turbine, injection machinery, auto mould and so on. Stocking supplier of bushings made from bronze, brass, aluminum-bronze, copper bushes, titanium and high temperature alloys. Secondary services include bar grinding, heat treating, trepanning, saw cutting and machining. Served the commercial, automotive, medical, electronic, food preparation, military, repair, pump and power generation industries. Meets the standards self-lubricating bearing bushing material. Made to order from China, Copper Bushing Manufacturer. Cast Bronze Bearing Supplier.
Copper Bushing Material Customized Bronze Copper Bushes Parts
Bronze Bushing, Cual10ni5fe4， High Quality Copper Bushing With Competitive Price, 2.0966 material bronze parts and slide plate. Copper bushing bearings, with their distinctive properties, have solidified their place in various industries. By understanding their advantages, applications, and maintenance needs, industries can harness their full potential, ensuring machinery operates seamlessly and efficiently.
Casting Bronze Bearings, cual10ni5fe4 bronze parts
The Self-lubricating Bushings that can do more – Custom Bearings Size Options, Copper bushes and bronze bushings with graphite are essential components in various mechanical and industrial applications due to their excellent wear resistance and self-lubricating properties.
Copper Bushes
Copper bushes are typically made from various copper-based alloys and are prized for their excellent thermal conductivity and resistance to corrosion. They are used in applications where heat dissipation is crucial, such as electrical systems and motors.
Bronze Bushing with Graphite
Bronze bushings with graphite have a unique structure:
-
Material Composition: These bushings are usually made from bronze alloys, which might include elements like tin or aluminum. Graphite is incorporated into the bushings either by embedding graphite plugs into the surface or by impregnating the bronze with graphite.
-
Self-Lubricating Feature: The graphite acts as a lubricant, which is particularly beneficial in environments where lubrication is difficult or if the application must remain free of external lubricants. This makes them ideal for high-load and high-temperature applications.
-
Applications: These bushings are used in various industries, including automotive (for components like gears and bearings), heavy machinery, and equipment used in corrosive environments. They are also found in hydraulic cylinders, gear pumps, and agricultural machinery.
-
Advantages:
- Reduced Maintenance: No need for regular lubrication.
- Durability: Highly durable under heavy load and high temperature.
- Corrosion Resistance: Offers excellent resistance against environmental elements.
-
Considerations:
- Cost: Generally more expensive than standard bushings due to the addition of graphite.
- Installation: Requires precise installation as improper alignment can lead to premature wear or failure.
These components are critical in ensuring the smooth operation of machinery by reducing friction and wear, and their self-lubricating properties help extend the life of the machines in which they are used. If you have a specific application or a technical question about these bushings, feel free to ask!
An Overview of Bronze Bearing Bushings: A Look into CuSn7Zn4Pb7 (C93200)
Bearings, in their various forms, play an integral role in any machinery that involves rotational or linear movement. Among these, the bronze bearing bushings have earned their place as a reliable and efficient type of bearing, known for their resilience, durability, and resistance to wear and friction.
Bronze bearing bushings, as the name suggests, are made of bronze, a versatile alloy typically consisting of copper and various other elements like tin, aluminum, silicon, or zinc. These bushings offer advantages over other types of bearings, such as high load carrying capacity, excellent resistance to wear and corrosion, and good thermal conductivity.
One particular type of bronze used in the manufacture of bearing bushings is the CuSn7Zn4Pb7 alloy, also known as C93200 or tin bronze rg7.
CuSn7Zn4Pb7 (C93200) Bronze Bearing Bushings
CuSn7Zn4Pb7 bronze is a high-tin alloy, widely regarded for its excellent load-carrying capacity, wear resistance, and durability. Here’s a look at the features and benefits of this alloy:
- High Load Capacity: The high tin content in CuSn7Zn4Pb7 bronze bearing bushings contributes to a high load-carrying capacity, making them ideal for applications with heavy loads.
- Superior Wear Resistance: These bushings exhibit a high resistance to wear and tear, extending their lifespan and reducing the need for frequent maintenance or replacement.
- Excellent Corrosion Resistance: CuSn7Zn4Pb7 bronze bushings are highly resistant to corrosion, making them suitable for applications in harsh environments or where the bearing may come in contact with corrosive substances.
- Good Thermal Conductivity: This type of bronze has good thermal conductivity, ensuring efficient heat dissipation during operation and helping to reduce the risk of overheating.
- Dimensional Stability: With good dimensional stability, these bushings maintain their form and fit even under adverse conditions, ensuring the smooth operation of the machinery they’re a part of.
Overall, C93200 bronze bearing bushings serve as robust, reliable, and efficient components in various mechanical applications. The specific blend of properties that CuSn7Zn4Pb7 brings to the table ensures that these bushings can handle an array of conditions, from heavy loads to harsh environments, while providing reliable and efficient service throughout their lifespan.
The Main Types of Bearing
|
Chemical Composition (CuSn7Zn4Pb7) |
|||||||
|
|||||||
Copper Bushings: An Essential Component in Industrial Applications
Copper bushings are an essential component in a variety of industrial applications, particularly in the electrical and mechanical industries. These cylindrical-shaped parts are used to reduce friction and to provide a smooth surface for a rotating shaft to pass through. Copper bushings provide a low-friction interface between the shaft and the component it’s rotating in, ensuring longevity and efficiency in the equipment.
Types of Copper Bushings
There are two main types of copper bushings: plain copper bushings and flanged copper bushings. Plain copper bushings are used in applications where there is no need for a flange, while flanged copper bushings are used in applications where the flange is needed to secure the bushing in place. Flanged copper bushings are typically found in applications where high loads and stresses are present, and they provide a stronger connection compared to plain copper bushings.
Applications of Copper Bushings
Copper bushings are used in a variety of industrial applications, including electrical motors, generators, transformers, and power transmission equipment. They are also commonly used in machine tools, pumps, compressors, and other rotating machinery. The electrical conductivity of copper makes it an ideal material for use in electrical applications, where it can help to dissipate heat and reduce the risk of electrical arcing.
Advantages of Copper Bushings
Copper bushings have several advantages over other materials, including:
- High electrical conductivity: Copper is an excellent conductor of electricity, which makes it ideal for use in electrical applications where high currents are present.
- Low friction: Copper bushings have a low coefficient of friction, which makes them ideal for use in applications where reducing friction is important. This can result in a reduction in wear and tear on the equipment and longer equipment lifespan.
- Durability: Copper bushings are highly durable and can withstand high loads and stresses, making them ideal for use in heavy-duty industrial applications.
- Corrosion resistance: Copper is resistant to corrosion, which makes it ideal for use in harsh environments where other materials would quickly deteriorate.
- Cost-effectiveness: Copper bushings are a cost-effective solution for industrial applications compared to other materials, such as bronze or stainless steel.
Conclusion
Copper bushings are a versatile and essential component in a variety of industrial applications. Their electrical conductivity, low friction, durability, corrosion resistance, and cost-effectiveness make them an ideal choice for use in electrical motors, generators, transformers, machine tools, pumps, compressors, and other rotating machinery. Whether you need a plain copper bushing or a flanged copper bushing, you can rely on this component to provide reliable and efficient performance in your industrial equipment.
The Main Types of Bearing China 2.0966 C63000 C63200 Copper Alloy Aluminum Bronze Bar …)
CuAl10Ni5Fe4
| Chemical Composition mass/% | |||||||||
|---|---|---|---|---|---|---|---|---|---|
| Cu | Sn | Al | Fe | Mn | Ni | Pb | Si | P | Zn |
| Rem | 0.1 | 8.5-11.0 | 3.0-5.0 | 1 | 4.0-6.0 | 0.05 | 0.2 | – | 0.4 |
| Mechanical properties | |||
|---|---|---|---|
| Tensile strength Mpa(Min) | Yield strength MPa(Min) | Elongation % | Brinell hardness(HB) |
| 600-1100 | 400-530 | 35-5 | 170-220 |
Symbol： C63000
Number：
Category： ASTM Wrought Copper Alloy
Type：63000 bronze bushing parts
| Chemical Composition mass/% | |||||||||
|---|---|---|---|---|---|---|---|---|---|
| Cu | Sn | Al | Fe | Mn | Ni | Pb | Si | P | Zn |
| Rem | 0.2 | 9.0-11.0 | 2.0-4.0 | 1.5 | 4.0-5.5 | – | 0.25 | – | 0.3 |
| Mechanical properties | |||
|---|---|---|---|
| Tensile strength Mpa(Min) | Yield strength MPa(Min) | Elongation % | Brinell hardness(HB) |
| 600-1100 | 345-600 | Sep-45 | 140-225 |
Category：ASTM Wrought Copper Alloy
Type：bronze parts with graphite
| Chemical Composition mass/% | |||||||||
|---|---|---|---|---|---|---|---|---|---|
| Cu | Sn | Al | Fe | Mn | Ni | Pb | Si | P | Zn |
| Rem | – | 8.7-9.5 | 3.5-4.3 | 1.2-2.0 | 4.0-4.8 | 0.02 | 0.1 | – | – |
| Mechanical properties | |||
|---|---|---|---|
| Tensile strength Mpa(Min) | Yield strength MPa(Min) | Elongation % | Brinell hardness(HB) |
| 621-950 | 310-365 | 9-25 | 120-210 |
CuSn5Zn5Pb5 Bronze Bearing Bushings: An Overview
The CuSn5Zn5Pb5 bronze alloy, often used in bearings and bushings, is a well-regarded material in several industrial applications. Its remarkable attributes, including its strength, durability, and corrosion resistance, make it a prime choice for creating robust and resilient mechanical components.
CuSn5Zn5Pb5 Bronze Bearing Bushings
The CuSn5Zn5Pb5 bronze, sometimes referred to as a tin bronze or phosphor bronze, is frequently used to manufacture bearing bushings. Here’s an exploration of the key features and advantages of this particular bronze alloy:
- High Load Capacity: The high tin content in CuSn5Zn5Pb5 bronze bushings contributes to an impressive load-carrying capacity, making these bushings an excellent choice for heavy-duty applications.
- Exceptional Wear Resistance: CuSn5Zn5Pb5 bronze bushings have superior wear and tear resistance. This characteristic lengthens their service life, reducing the frequency of maintenance and replacement.
- Outstanding Corrosion Resistance: These bushings are highly resistant to corrosion. This resistance makes them suitable for applications in demanding environments or in situations where they may encounter corrosive substances.
- Thermal Conductivity: CuSn5Zn5Pb5 bronze offers good thermal conductivity, which facilitates efficient heat dissipation during operation. This feature helps to minimize the risk of overheating, thereby improving the performance of the machinery.
- Dimensional Stability: With excellent dimensional stability, these bushings maintain their form and fit under challenging conditions, ensuring the smooth functioning of the machinery in which they are integrated.
This particular alloy is often used in components that experience high loads, including centrifugal casting brass bushings, cone crusher bronze bushes, alloy brass bearing bushes, and more. These bushings are critical components in machinery used in a wide range of industries, including mining, construction, and manufacturing.
Overall, the CuSn5Zn5Pb5 bronze bearing bushings stand as a reliable, efficient, and durable choice for various mechanical applications. The unique combination of attributes that this alloy provides ensures that these bushings can withstand diverse conditions, from heavy loads to harsh environments, while consistently delivering reliable and efficient service.
Bushings • Plain (copper) Bearings
|
Alloy Chemical Composition (CuSn5Zn5Pb5) |
|||||||||||
|
|||||||||||
Oil Grooves & Oil Pockets
Bronze Bushing Groove Types: An Overview
Bronze bushings are crucial components in many mechanical applications, providing a surface for low-friction sliding within the mechanism. Depending on the application, these bushings can be equipped with different groove types to enhance their functionality. One such type is a graphite oil groove.
Graphite Oil Grooves
Graphite oil grooves are often incorporated in bronze bushings to provide consistent lubrication. The graphite within these grooves acts as a solid lubricant, reducing friction and wear between the bushing and the mating surface.
Benefits of Graphite Oil Grooves:
- Self-lubrication: Graphite oil grooves eliminate the need for frequent lubrication, making them a great choice for hard-to-reach or maintenance-intensive applications.
- Reduced Friction: The graphite acts as a lubricant, reducing friction and subsequently the heat generated during operation. This leads to increased bushing and machinery lifespan.
- Lower Maintenance: Due to the self-lubricating properties of graphite, bushings with graphite oil grooves require less maintenance compared to those without.
Other Groove Types:
- Spiral Grooves: These are often used in high-speed applications to ensure proper oil flow and retainment. The spiral pattern helps distribute the lubricant evenly across the bushing’s surface.
- Linear Grooves: Often used in low-speed, high-load applications, linear grooves offer excellent lubrication retention, but they require the application to have some form of relative motion to ensure proper lubricant distribution.
Materials:
Bronze bushings can be made from various alloys, including cast bronze, aluminum bronze, and brass. The choice of material largely depends on the specific application’s needs. For instance, cast bronze offers excellent load-bearing capabilities, while aluminum bronze provides superior resistance to wear and corrosion.
When it comes to replacing a bushing, considering the groove type and the material is crucial to ensure the replacement part can perform as expected and extend the overall lifespan of the machinery. Different groove types offer various advantages, so the choice should be based on the application’s specific lubrication needs and operational parameters.
Copper Bushing Available Bronze Bearing Alloy
Available Bronze Bearing Alloy ALLOY TYPE STANDARD DIN STANDARD ASTM STANDARD (NEAREST EQUIVALENT)OTHER COMPATIBLE ALLOYS
Key Applications of Copper Bushing Bearings
Copper bushing bearings, due to their unique properties, find applications in:
Automotive Industry: In engines, transmissions, and braking systems.
Electrical Equipment: Given copper’s conductivity, they are used in generators, transformers, and other electrical apparatus.
Industrial Machinery: In pumps, turbines, and other heavy-duty equipment.
Marine Applications: Their resistance to corrosion makes them ideal for marine environments.
| Aluminum Bronze Bearing | CW307G | CuAl10Ni | C63200 / C63000 | NES833, BSB23(DTD197A) |
| Aluminum Bronze Bearing | – | CuAl10Fe3Ni7Mn2 | C63000 | – |
| Aluminum Bronze Bearing | CC331G | CuAl10Fe2-C | C95400 | SAE68 |
| Aluminum Bronze Bearing | CC333G | CuAl10Fe5Ni5-C | C95500 | SAE68B |
| Leaded Bronze Bearing | CC496K | CuSn7Pb15-C | C93800 | SAE67 |
| Leaded Bronze Bearing | CC495K | CuSn10Pb10-C | C93700 | SAE64 / SAE797 / SAE792 |
| Leaded Bronze Bearing | CC494K | CuSn5Pb9-C | C93500 | SAE66 |
| Leaded Bronze Bearing | CC497K | CuSn5Pb20-C | C94100 | SAE94, SAE794 & SAE799. |
| Leaded Bronze Bearing | – | CuSn7ZnPb | C93200 | SAE660 |
| Leaded Gunmetal | CC491K | CuSn5Zn5Pb5-C | C83600 | SAE40 |
| Leaded Gunmetal | CC492K | CuSn7Zn2Pb3-C | C93400 | – |
| Leaded Phosphor Bronze Bearing | – | CuSn8Pb4Zn1 | C93100 | – |
| Leaded Phosphor Bronze Bearing | CC480K | CuSn10-C | C92700 | – |
| Nickel Gunmetal | – | CuSn7Ni5Zn3 | B292-56 | – |
| Phosphor Bronze Bearing | CW450K | CuSn4 | C50900 C51100 | – |
| Phosphor Bronze Bearing | CW451K | CuSn5 | C51000 | NES838 |
| Phosphor Bronze Bearing | CW452K | CuSn6 | C51900 | – |
| Phosphor Bronze Bearing | CW459K | CuSn8 | C52100 | BSB24 DTD265A |
| Phosphor Bronze Bearing | – | – | – | BSB24, PB104 |
| Tin Phosphor Bronze Bearing | CC481K | CuSn11P-C | B143 | SAE65 |
| Tin Phosphor Bronze Bearing | CC483K | CuSn12-C | CC483K |
Cast Bronze Copper Bushing Bearing: Material and Specifications
The Cast Bronze Copper Bushing Bearing is a low-maintenance, durable component made from various types of copper alloys such as CuSn7Zn4Pb7 and CuSn5Zn5Pb5. These materials offer excellent mechanical properties like good wear resistance, corrosion resistance, and improved bearing performance. Additionally, other aluminum bronze bearing materials are available based on the specific application requirements.
Here are some key specifications of these bearings:
Standard Manufacturing Protocols The bearings can be manufactured according to numerous international standards, reflecting their wide acceptance and usage across industries. Some of these standards include:
- DIN 17670/ 17672/17673/17678-1: These are German standards that outline the requirements for wrought copper and copper alloy products.
- EN 12163/12165/12167/12420 CW307G: These are European Standards for copper and copper alloys.
- ASTM B 150, B124, B171 C63000: American Society for Testing and Materials (ASTM) standards specific to the C63000 Nickel Aluminum Bronze.
- SAE AMS4640, SAE AMS 4590, SAE J463, J461: These are standards set by the Society of Automotive Engineers (SAE) for various types of copper and copper alloy products.
- MIL-B-16166: A US military standard for bronze rod, bars, and shapes.
- ASME SB150 C63000: American Society of Mechanical Engineers (ASME) standard for Nickel Aluminum Bronze C63000.
- QQ-C-465 Amd1: A federal specification for copper-zinc-lead alloy (leaded-brass) extruded shapes.
- AS/NZS 1567: Australian/New Zealand standard for wrought copper and copper alloy products.
- GOST 16: A Russian standard for various copper alloy products.
All these standards ensure that the bearings conform to universally accepted manufacturing protocols, ensuring optimal performance and durability. It’s essential to choose a manufacturer with a proven track record of producing high-quality bronze bushings that meet these specific needs and requirements.
Copper bushing designed completed reliably from manufacturing to delivery.
Cast Bronze Bushing: Specifications and AvailabilityL Cast bronze bushings are robust and versatile components extensively used in various industries due to their excellent mechanical properties. The following are specifications for the Cast Bronze Bushing, available in continuous cast bushing and stocked metric sizes.
Availability: Cast Bronze Bushings are available in both metric and inch sizes. The most commonly used bronze for these bushings is the CuAl10Ni5Fe4, also known as C63000 bronze. This material is suitable for a broad range of applications due to its remarkable resistance to wear, corrosion, and fatigue.
Mechanical Properties: CuAl10Ni5Fe4, commonly referred to as Nickel Aluminum Bronze, is a high strength copper-based alloy. Here are some mechanical properties of this material:
Tensile Strength: It boasts a high tensile strength, making it resistant to deformation under high-stress conditions.
Hardness: This alloy demonstrates excellent hardness, which results in an extended wear life of the bushing.
Corrosion Resistance: The material displays high corrosion resistance, making it ideal for applications in harsh environments.
bronze bushing and Copper Bushes components for reliable usage.
The Nickel Aluminium Bronze Bushing, also known by its nominal composition CuAl10Ni5Fe4, is a type of bushing that uses a wrought alloy. Wrought alloys undergo the process of deformation (rolling, forging, extruding, etc.) to improve certain properties and shape the material into a specific form. This process enhances the durability, strength, and wear resistance of the bushing.
Worldwide, CuAl10Ni5Fe4 is recognized by various names such as AlBz10Ni, AlBz10Ni5, and 2.0966, all referring to the same material specification for this Nickel Aluminium Bronze Bushing.
It’s important to choose a reputable manufacturer with a proven track record of producing high-quality cast bronze bushings that meet your specific needs and requirements.
Technical Data Sheet. CuAl10Ni. Aluminium bronze. Continuous Cast Bushing and Bronze Graphite Parts.
Trusted & reliable copper bushing supplier
High Performance Cast Copper Bushing & Bronze Bearings Designed in Collaboration with Customers. Made for Your Needs. Speak to an Engineer to Learn More about Our Custom, High Quality Copper Bearings. Metric groove bronze bushings & imperial bronze bushes.
Quality, service and innovative process and production methods.
Get free shipping on qualified bushing, copper bushing & cast bronze with graphite bushes. A large range of copper bushing at www.bronzelube.com supply. Advantages of Using Copper Bushing Bearings
- Durability: Given their resistance to wear and corrosion, copper bushings tend to have a long lifespan.
- Efficient Operation: Their natural anti-friction properties ensure machinery operates smoothly.
- Heat Dissipation: Copper’s ability to dissipate heat effectively reduces the risk of machinery overheating.
- Cost-Efficiency: Given their longevity and minimal maintenance needs, copper bushings can be a cost-effective solution in the long run.
View the copper bushing catalog online.
