SWP Oiless Wear Plate Copper self-lubricating Plate
Flat Plate Oilless Flat Plate with Graphite Plugs, High tensile brass based / solid lubricant embedded
SWP Oiless Wear Plate material is made with high-strength copper alloy, and the inserted solid lubricant materials are made with graphite and PTFE.
High-strength copper alloy as base material, according to the use conditions by a certain percentage of its working surface machined hole and fill one solid lubricant. High-strength copper alloy provides a high load-carrying capacity and the solid lubricant can be formed at lower friction. Under dry friction conditions of our pre-designed layer of lubricating film in the bearing surface to ensure that in the shortest possible time will be transferred to the solid lubricant on the coupling member and form a valid solid lubricant film.
Graphite Slide Plates – Bronze Products
Graphite Slide Plates. Graphite oilless bronze plate, bronze slide plates for higher temperature applications.
According to the bushings’ working conditions, the bronze combination between the different metal basements and various solid lubricants can ensure that the product can perform under various temperatures, loads, movements and mediums as required.
Oilless bush is especially applied in oil-free high temperature, high load, low speed, contamination resistance, corruption resistance radiation resistance as well as the use under such special work conditions that cannot be lubricated, such as underwater and in vacuum space.
Below is a table chart of SWP Oilless Wear Plate sizes. Please note that this table is an example and may not represent the entire range of sizes available. For accurate measurements and more options, refer to the manufacturer’s datasheets.
| Wear Plate Size | Length (L) | Width (W) | Thickness (T) |
|---|---|---|---|
| Size 1 | 50 mm | 50 mm | 2 mm |
| Size 2 | 100 mm | 50 mm | 2 mm |
| Size 3 | 100 mm | 100 mm | 2 mm |
| Size 4 | 150 mm | 100 mm | 3 mm |
| Size 5 | 200 mm | 100 mm | 3 mm |
| Size 6 | 200 mm | 200 mm | 3 mm |
| Size 7 | 250 mm | 200 mm | 4 mm |
| Size 8 | 300 mm | 200 mm | 4 mm |
| Size 9 | 300 mm | 300 mm | 4 mm |
| Size 10 | 400 mm | 300 mm | 5 mm |
| Size 11 | 500 mm | 300 mm | 5 mm |
| Size 12 | 500 mm | 500 mm | 5 mm |
| Size 13 | 600 mm | 500 mm | 6 mm |
| Size 14 | 700 mm | 500 mm | 6 mm |
| Size 15 | 800 mm | 500 mm | 6 mm |
This table provides information on the length (L), width (W), and thickness (T) of the SWP Oilless Wear Plates. To find the appropriate wear plate size for your application, check the manufacturer’s guidelines for the correct dimensions and tolerances.
SWP plate is made with high-strength copper alloy, and the inserted solid lubricant materials are made with graphite and PTFE.
According to the bushings’ working conditions, the bronze combination between the different metal basements and various solid lubricants can ensure that the product can perform under various temperatures, loads, movements, and mediums as required.
Oilless bush is especially applied in oil-free high temperature, high load, low speed, contamination resistance, corruption resistance radiation resistance as well as the use under such special work conditions that cannot be lubricated, such as underwater and in vacuum space.
Wear Plate General Purpose Plate Key Characteristics:
1. May work without any oil for long period.
2. Extremely high load capacity, good anti-wear, and low friction.
3. Particularly appropriate for low speed and high load.
4. Suitable single direction axial loads
5. Free design is possible on the shape and size
6. Can be used in a wide range of temperatures, from － 40℃＋ 300℃
Bronze Wear Strips – Holes- Graphite, Bronzelube.com
High tensile brass based / solid lubricant embedded plat
| Slide Bronze Wear Plate SWP-100100 |
| Slide Bronze Wear Plate SWP-100125 |
| Slide Bronze Wear Plate SWP-100150 |
| Slide Bronze Wear Plate SWP-100200 |
| Slide Bronze Wear Plate SWP-100250 |
| Slide Bronze Wear Plate SWP-125150 |
| Slide Bronze Wear Plate SWP-125200 |
| Slide Bronze Wear Plate SWP-125250 |
| Slide Bronze Wear Plate SWP-150150 |
| Slide Bronze Wear Plate SWP-150200 |
| Slide Bronze Wear Plate SWP-150250 |
| Slide Bronze Wear Plate SWP-48100 |
| Slide Bronze Wear Plate SWP-48125 |
| Slide Bronze Wear Plate SWP-48150 |
| Slide Bronze Wear Plate SWP-4875 |
| Slide Bronze Wear Plate SWP-75100B |
| Slide Bronze Wear Plate SWP-75125 |
| Slide Bronze Wear Plate SWP-75150 |
| Slide Bronze Wear Plate SWP-75200 |
| Slide Bronze Wear Plate SWP-7575B |
The specifications and dimensions of the Bronze Wear Plate may not be fully covered. For exact details, refer to manufacturer oilless bearing catalogs.
Injection mold in the sliding parts basically need to do oil groove, with lubricating oil to ensure the smooth movement of the mold structure, wear and lubrication, such as: slant pin, slider, top block and other parts. Oil groove applicable parts: slider, slider insert, slant pin, wear-resistant block, wedge block, top block and other moving parts of the sliding surface must be processed oil groove. I. Oil groove design standards: 1. Design non-standard slider (overall slider), slider inserts, top block need to draw 3D, 2D, and mark the size of the nearest edge of the rubber surface to the oil groove in 2D (to avoid processing errors). 2. When designing slant pins, slider guide blocks, wedge tight blocks, oil grooves do not need to draw 3D, 2D oil grooves, made into a standard specification file can be. II. Oil groove processing standard Applicable parts: slider, slider insert, tilt pin, wear-resistant block, wedge block, top block and other moving parts of the sliding surface must be processed oil groove. Description: 1. Circle-shaped oil groove: diameter Φ10, Φ8, Φ6, Φ2.5 circle, circle center distance are 8*8, 6*6, 5*5, 2*2 (unit: mm) oil groove depth is 0.3±0.05mm (for the slider, slant pin) 2. ±0.05mm; for sliding parts with face width below 5.5mm (for slant pins). Processing basis: strictly in accordance with the standard oil groove processing schematic for each part. Machining process: Standard parts: Standard parts of the old factory are processed by the standard parts group (grinder, milling machine) of the machining department; all slant pin oil grooves are processed by the standard parts group (EDM); Non-standard parts: Non-standard parts are processed by the machining section (grinder, milling machine) of each department; Machining Remarks: Screw holes, part edges, etc. are not to be broken during machining.
Chinese (Simplified)
Injection mold on the sliding parts basically needs to do oil groove, with lubricant to ensure smooth movement of the mold structure, wear-resistance, and lubrication, such as slant pin, slider, top block, and other parts. Oil groove applicable parts: slider, slider inserts, slant pin, wear-resistant block, wedge tight block, top block, and other moving parts on the sliding surface of the necessary processing oil groove. I. Oil groove design standards: 1. Design non-standard slider (overall slider), slider inserts, top block need to draw 3D, 2D, and mark the size of the nearest edge of the rubber surface to the oil groove in 2D (to avoid processing errors). 2. When designing slant pins, slider guide blocks, wedge tight blocks, oil grooves do not need to draw 3D, 2D oil grooves, made into a standard specification file can be. II. Oil groove processing standard Applicable parts: slider, slider insert, tilt pin, wear-resistant block, wedge block, top block and other moving parts of the sliding surface must be processed oil groove. Description: 1. Circle-shaped oil groove: diameter Φ10, Φ8, Φ6, Φ2.5 circle, circle center distance are 8*8, 6*6, 5*5, 2*2 (unit: mm) oil groove depth is 0.3±0.05mm (for slider, slant pin) 2. ±0.05mm; for sliding parts with face width below 5.5mm (for slant pins). Processing basis: strictly in accordance with the standard oil groove processing schematic for each part. Machining process: Standard parts: Standard parts of the mold factory are processed by the standard parts group (grinder, milling machine) of the processing department; slant pin oil grooves are all processed by the standard parts group (EDM); Non-standard parts: Non-standard parts are processed by the processing section (grinder, milling machine) of each department; Processing Remarks: Screw holes, part edges, etc. are not to be broken during processing.
Frequently Asked Questions about Wear Plates
Can I use two copper-plated wear plates in a mold and have the two plates rub against each other?
This is not recommended (having the two plates rub against each other). The material to rub against the copper-plated wear plate should be different and harder than the copper-plated plate. It is recommended that the material intended to rub against the copper-plated wear plate should have a difference of at least 6-8 HRc hardness points (higher) compared to the surface hardness of the copper-plated wear plate itself.
I operate a clean room facility. What kind of residue do I expect the wear plate to leave behind?
Materials. Copper and tin. In this case, it is recommended that the wear plates be placed as far away from the cavity as possible. Use grease or oil to reduce wear.
I want to drill holes in a self-lubricating wear plate. How can I find out where the graphite insert is located?
Please contact our engineering company for assistance. You will need to provide your specific part number.
Is there an upper-temperature limit for copper-plated wear plates, slides, and skids?
Copper-plated wear plates, slides, and gears can be used at operating temperatures up to 400°F (204°C).
What are copper-plated wear plates, slides, and gears made of?
Copper-plated wear plates, slides, and gears are made from low carbon, ultra-fine grain steel plated with a bronze alloy. Bronze has a minimum hardness of approximately 180 Bhn (for hardness conversion tables, please refer to the Die Holders and Stencils catalog). The bronze plating has natural lubricity and is ideal when used against hardened steel. We recommend using any good grade of light machine oil suitable for application in a mechanical manner to extend the life of the wear surface.
What is the coefficient of friction of your bronze-plated wear plates, guides, and capstans?
Self-lubricating wear plates are made of aluminum bronze alloy and have oil-impregnated graphite plugs.
What is the difference between copper-plated wear plates and self-lubricating wear plates?
Self-lubricating wear plates are made of aluminum bronze alloy and have oil-impregnated graphite plugs.
What is the maximum pressure that can be applied to a copper-plated wear plate?
2700 PSI (pounds per square inch).
When should I replace a copper-plated wear plate?
After 0.003″ (approximately 0.076 mm) of maximum wear.
