C94100

Bearings and Bushings for the Future: Precision and Customization: Our company, in bearing engineering with decades of experience, designs and develops high-precision self-lubricating bronze bearings & plain bushes. We offer a wide array of sliding bearings tailored to meet specific needs. Renowned for our expertise in custom bronze bushing and slide plate solutions, we provide an expansive selection of bushing metal alloys. Contact us today to benefit from unparalleled services at competitive prices.

C94100

Oilless bronze bearing bush self-lubricating with ...

C94100 Alloy, C941 High Leaded Tin Bronze – Bronze Bearing, CuSn5Pb20

Chemical Composition mass/%
Cu Sn Al Fe Mn Ni Pb Si P Zn
72.0-79.0 4.5-6.5 0.01 0.25 1 18.0-22.0 0.01 1.5 1
Mechanical properties
Tensile strength Mpa(Min) Yield strength MPa(Min) Elongation % Brinell hardness(HB)
172 117 7 50

Copper, lead and tin bronze alloy

CuSn5Pb20-C is the EN chemical designation with low heat capacity among cast bronzes, very low tensile strength, and a low melting temperature. CuPb20Sn5, also known as Leaded Bronze, falls under Grade CuSn5Pb20-C and is classified as a Copper-tin-lead alloy.

The Superior Choice for Industrial Applications: Large Size C94100 Cast Bronze Bearings

In the realm of industrial machinery, the choice of bearing material is crucial for ensuring optimal performance and longevity. Among the various options available, the C94100 cast bronze bearing stands out, particularly for large-scale applications. This blog post delves into the unique properties of C94100 cast bronze bearings, their applications, and why they are a preferred choice in industries requiring robust and reliable components.

Unveiling the C94100 Cast Bronze Bearing

The C94100 cast bronze bearing is crafted from a high-quality copper alloy known for its excellent wear resistance and durability. This alloy conforms to established bronze standards, making it an ideal choice for heavy-duty applications. The composition of C94100 bronze includes elements like tin and lead, which enhance its machinability and resistance to fatigue and wear.

Key Features and Benefits

Durability and Resistance: The primary advantage of C94100 bronze bearings is their outstanding durability. The alloy’s resistance to wear and corrosion makes it suitable for environments where other materials might fail. This ensures longer service life and reduced maintenance costs.

Versatility: These bearings are highly versatile and can be used in a variety of industrial applications. Whether it’s high-speed machinery or high-load equipment, C94100 bearings maintain their integrity and performance.

Compliance with Standards: Adhering to strict bronze standards, C94100 bearings ensure consistent quality and reliability. This compliance is critical for industries that require components to withstand rigorous operational conditions.

Applications of Large Size C94100 Cast Bronze Bearings

Large size C94100 cast bronze bearings are particularly valuable in heavy machinery and industrial applications where robustness and reliability are paramount. Common applications include:

  • Marine Engineering: Used in shipbuilding and repair, where components are exposed to harsh marine environments.
  • Mining and Construction: Essential for equipment subjected to high loads and abrasive conditions.
  • Energy Sector: Ideal for power generation equipment, including turbines and generators that require high-performance bearings.

Why Choose C94100 Cast Bronze Bearings?

Choosing the right bearing for your industrial needs can significantly impact the efficiency and cost-effectiveness of your operations. Large size C94100 cast bronze bearings offer several compelling reasons for their selection:

  • Longevity: With enhanced durability, these bearings reduce the frequency of replacements and downtime, which can lead to substantial cost savings over time.
  • Performance: Their ability to withstand tough conditions without compromising performance makes them an invaluable component of any heavy-duty machinery.
  • Cost-Effectiveness: Although they might have a higher upfront cost compared to other materials, the long-term savings in maintenance and replacement costs make them a wise investment.

C94100 Bronze bearing

For industries looking to enhance the performance and reliability of their heavy machinery, large size C94100 cast bronze bearings are a standout choice. Their robust construction, adherence to bronze standards, and versatility across applications make them an essential component in demanding industrial environments. When reliability and performance are non-negotiable, C94100 bronze bearings deliver time and again.

Start Learning to Bronze Bearing Material

Contact us to schedule your Copper Continuous Cast Alloy (UNS C94100).

C94100 High Leaded Tin Bronze, CuSn5Pb20

C94100 ASTM Casting Copper Alloy

We can manufacture copper alloy material according to China’s national standard, as well as the ASTM (UNS, SAE), EU, and JIS standards. Additionally, we can develop copper alloy material based on customers’ specific requirements and drawings. CuSn5Pb20-C is the EN chemical designation. It has a very low heat capacity among cast bronzes. In addition, it has a very low tensile strength and a very low melting temperature.Please let us know if you have any specific requirements or drawings for copper alloy materials, and our team will work closely with you to develop the perfect solution. CuSn5Pb20-C is just one example of the high-quality copper alloy materials we can provide, and we are dedicated to meeting the unique needs of each of our customers.
