The C83600 Custom Machined Parts, C836 / C83600 Leaded Red Brass Alloy

About us

Cost-Effective C83600 Bronze Bushings for Low-Load Bearings

C83600 Red Brass is a copper alloy known for its excellent corrosion resistance, good mechanical properties, and appealing appearance. It primarily consists of copper with zinc and sometimes small amounts of lead to enhance machinability. This red copper alloy is widely used for bearings and components needing wear resistance. Though called bronze, it is more often referred to as brass and is commonly used for bearing bushings in various industrial applications due to its outstanding performance and durability.fe.

ZCuSn5Pb5Zn5 C83600 Bronze Bearings, 1C83600 Alloy, C836 Leaded red brass
C83600 Bronze Graphite Bearing, C83600 Alloy, C836 Leaded Red brass Bushes

key points about C83600 Red Brass, C83600 Alloy, C836 Leaded red brass Bearing

Brass composition: red brass composition, C83600 Leaded Red Brass, commonly referred to as 85 metal or 85-5-5-5, is the most prevalent type of red brass bar. It is composed of 85% copper, with each of tin, lead, and zinc making up 5%.

Corrosion Resistance: The high copper content in C83600 Red Brass makes it resistant to many forms of corrosion, which is beneficial for components that may be exposed to various environmental conditions.

Mechanical Properties: This alloy has good mechanical properties, including strength and hardness, which are important for bearing applications where the material needs to withstand loads and maintain its shape.

Non-Ferrous: Being a non-ferrous metal, C83600 Red Brass does not have magnetic properties, which can be an advantage in applications where magnetic interference is undesirable.

Low-Load Bearings: For low-load bearing applications, the combination of strength, corrosion resistance, and non-magnetic properties makes C83600 Red Brass a suitable and economical choice. It can handle the low to moderate loads typically found in such applications without the need for more expensive materials.

C836 / C83600 Leaded Red Brass Alloy, Benefits Of c836 Bronze Bushing For Such Applications:

Cost-Effectiveness: Compared to other materials like stainless steel or more complex alloys, C83600 Red Brass can be a more cost-effective option for certain applications, particularly where the loads are not too high.

Machinability: The addition of lead can enhance the machinability of the alloy, making it easier to manufacture components with tight tolerances and complex geometries.

Aesthetics: Red Brass has a distinctive reddish color that can be appealing in applications where appearance is also a consideration.

Non-Toxic: Red Brass is often used in applications where contact with food or beverages is possible, as it is considered non-toxic.

C836 / C83600 Leaded Red Brass Alloy Bearings
Bronze alloy 936 Cast Bronze Flanged Bushing/bearing Bronze With Graphite

C83600 Red Brass, cusn5zn5pb5 material, C836 / C83600 Custom Parts

It’s important to note that while C83600 Red Brass can be a good choice for low-load bearing applications, it may not be suitable for high-load or high-wear applications where more robust materials would be required. Additionally, the specific properties and suitability of C83600 Red Brass can vary depending on the exact formulation and any heat treatment or processing it has undergone.

The Chinese equivalent of C83600 is ZCuSn5Pb5Zn5. C83600 is an American standard bronze alloy, primarily composed of tin as the main alloying element in the copper base. It is widely used in industries such as shipbuilding, chemicals, machinery, and instrumentation.

Copper Alloy Bushing -Tin Bronze, C83600 Tin Bronze

Experience the Strength of Self-lubricating Bearings

Bronze Material: Red brass alloys, like C836, C836 / C83600 Leaded Red Brass Alloy Bearing Bushing

C83600 Leaded Red Brass, or 85 metal, is a widely used alloy containing 85% copper and 5% each of tin, lead, and zinc. It is frequently employed in plumbing applications. The most common in this group is C84400 semi-leaded red brass, valued for its cost-effectiveness and excellent machining and casting properties, with lead enhancing pressure tightness. Red brass is also a budget-friendly choice for low-load bearings.

We offer machining, design, and engineering services characterized by integrity, quality, and commitment. Our products include affordable, high-quality, precision CNC machined parts. Our gallery highlights capabilities in CNC milling and turning, 5-axis CNC machining, and complex parts and assemblies production.

C89835 Lead-free replacement for C932, C836, C844

C89835 is a lead-free alternative to traditional bronze alloys such as C932, C836, and C844. It is used in the CNC machining of bronze parts, customized using the lead-free or low-lead C89835 and C932, C935 alloys.

C89835 is a lead-free replacement alloy for C932, C836, and C844, and is available as a standard-stocked product. This alloy meets the market demand for materials that comply with lead-free regulations.

  • bronze bush

    Get Your Instant Quote

  • Custom Machined Bushing – Groove Type – Cast Bronze Bearings

    Get Your Instant Quote

  • C93200 Bronze Parts

    Get Your Instant Quote

Copper Casting Alloy – Leaded Red Brass UNS C83600

Enhance Your Machinery with C83600 Alloy, C836 Leaded Red brass Bushings.

Your Source for Heavy-Duty Self-lubricating Bearings
