Bronze Plates
Bearings and Bushings for the Future: Precision and Customization: Our company, in bearing engineering with decades of experience, designs and develops high-precision self-lubricating bronze bearings & plain bushes. We offer a wide array of sliding bearings tailored to meet specific needs. Renowned for our expertise in custom bronze bushing and slide plate solutions, we provide an expansive selection of bushing metal alloys. Contact us today to benefit from unparalleled services at competitive prices.
Bronze Plates
Self-Lubricating Bronze Plate with Solid Lubricant Insert
Our bronze plates can be customized with various sizes, shapes, holes, patterns, pockets, chamfers, and cutouts. Upon ordering, your custom bronze plate will be fully assembled and ready for use. For a quote or to place an order, please contact us. We’re happy to assist!
Standard sizes
Bronze Plate
These plates are solid aluminum bronze with pre-drilled mounting holes and self-lubricating graphite.
professional Slide Plate
Supplier
Bronze Wear Strips – Holes and Graphite, Custom Wear Strips
Grease Groove Wear Plates
Focus
Self-lubricating Bronze Plate with Holes and Grease Grooves
Self-lubricating
Plate Custom Size
Graphite plugged bronze wear plates are available in various sizes. They come complete with self-lubricating graphite and are made of aluminum bronze.
Custom Wear Bronze Plate
Produces custom self-lubricating bronze plates tailored to meet customer specifications using top-quality materials. Our bronze plates have demonstrated success across diverse industrial applications.
Bronze plates are available in either bronze with self-lubricating graphite or in CuZn25Al6FeMn3 without graphite. Bronze plate, wear strips include special features such as size, shape, holes, hole pattern, pockets, chamfers and cutouts.
Available in the following configurations:
Wear Bronze Plates & Graphite Plugs Supplier
Discovery More the Graphite-Impregnated Bronze Plates. Self lubricating bronze custom plate. You will find to follow a selection of other formats of self lubricating bronze that we have manufactured. Are you interested in our slide bronze plates? Request a no obligation, tailored quote. Bronze plates are available in metric sizes. There is a large chamfer along the width of the part, which is ideal for some applications. Bronze plates are available in cast bronze CuZn25Al6FeMn3, CuSn12 or or CuPb5Sn5Zn5 or CuAl10Fe3 aluminum bronze with or without self-lubricating graphite or grease grooves.
CNC machining slide plates can produce complex, intricate parts or simple, flexible, and robust ones. Organizations looking for reliable, fast, cost-effective machining solutions typically partner with CNC service providers to ensure optimal results.
taxation planning
Eiusmod tempor incididunt ipsum ut labore dolore magna aliqua. Ut enim minim veniam duisy ipsum sed quis.
Get Your Free Quote – One stop wear Bronze Plate shop
Graphite-filled bronze is an excellent alternative to oil-filled bronze, offering dry lubrication at high temperatures. Our bronze plates perform effectively under slow, heavy-duty conditions requiring external lubrication and excel in the high temperatures of various industrial applications.
More information about our bronze graphite wear bronze plates and self-lubricating wear plates are available for self-lubrication.
These components are crafted from either solid aluminum bronze or bronze that features wear surfaces that have been hardened through a flame treatment process, both incorporating self-lubricating graphite. They are utilized in metal stamping dies and other applications where substantial forces are present. These gibs are fully compliant with the standards set by NAAMS.
Wear Resistant Bronze Slide Plates, Bronze Plate material, custom wear strips
Start Sourcing Bronze Plug Graphite Bearings To Drive Today. Give us a call to schedule your first order parts! Self Lubricating Wear Bronze Plates, Self lubricating bronze wear plates products & suppliers. However, we offer a full range and can also manufacture bronze alloys as per clients’ requirements: CuSn6Zn6Pb3 material, CuAl10Fe3, CuSn12, CuPb5Sn5Zn5,
CuZn25Al6FeMn3 and ASTM Classe40 – HT 250 are commonly used for small or large slide plates. Typical bronzes for bushings include aluminum bronzes, tin bronzes, and high tensile brasses. L-shaped plate materials, such as Phosphor Bronze (PB2) or copper alloys, include graphite inserts for wear resistance. Custom slide plates are available for your machine components.
taxation planning
Eiusmod tempor incididunt ipsum ut labore dolore magna aliqua. Ut enim minim veniam duisy ipsum sed quis.
Plastic Injection Molding- wear Bronze Plate Application, Slide Plates Made by CNC Machining
Exploring the Cost and Expertise in Injection Molding Bronze Plates involves understanding CNC, a computer-guided machining process for high-quality bronze components. This technology is vital for innovative tool and die makers. We offer design support for manufacturing injected bronze bearings.
CNC Production Machining bronze graphite wear bronze plates and self-lubricating wear plates for Production. CNC machining offers numerous advantages, producing metal wear plates and slide bronze bearings with precise tolerances. It enables the efficient, safe, and economical creation of slide plates and metal and bronze wear plate parts, surpassing other production methods. Bronze plate products made by CNC are ubiquitous, often unnoticed in our daily lives.
Injection mold bronze plates and bushings design, slide bushing bearing manufacturers!
Bronze Wear Plate and Steel Wear Plate are commonly used wear-resistant materials in industry. They can be enhanced with various features to improve performance and adaptability according to different needs. Here are the different types of bronze and steel wear plate you mentioned and their characteristics:
- Bronze Wear Plate – Plain:
- This is the most basic type of bronze wear strip, without any additional holes, lubrication grooves, or graphite coatings.
- Bronze Wear Plate – Graphite:
- These bronze wear plate strips have a graphite coating on the surface, which provides additional lubrication to reduce friction and wear.
- Bronze Wear Plate- Holes:
- These wear plate come with holes, facilitating easy installation and connection with other components.
- Bronze Wear Strips – Holes and Graphite:
- Combining the features of graphite coating and holes, they offer better lubrication and installation convenience.
- Bronze Wear Plate – Holes and Grease Grooves:
- These wear plates not only have holes but also specially designed grease grooves to store and direct lubricating oil, providing continuous lubrication.
- Steel Wear Strips – Holes:
- Steel wear strips with holes, used for installation and connection.
- Steel Wear Strips – Holes and Grease Grooves:
- Steel wear strips with holes and grease grooves are designed to provide better lubrication and wear resistance.
These different types of wear strips can be selected based on the specific requirements of the application to ensure optimal performance and durability. For example, if you need to reduce friction and wear, you can choose bronze wear strips with a graphite coating; if continuous lubrication is needed, you can opt for types with grease grooves.
Bronze Graphite Wear Plate, Bronze Plate Technical Data:
| Material | CuZn25AI5Mn4Fe3 | CuSn5Pb5Zn5 | CuAI10Ni5Fe5 | CuSn12 | CuZn25AI5Mn4Fe3 |
| Density | 8 | 8.9 | 7.8 | 8.9 | 8 |
| Hardness | ≥210 | ≥70 | ≥150 | ≥75 | ≥235 |
| Tensile strength | ≥750 | ≥250 | ≥500 | ≥270 | ≥800 |
| Yield strength | ≥450 | ≥90 | ≥260 | ≥150 | ≥450 |
| Elongation | ≥12 | ≥13 | ≥10 | ≥5 | ≥8 |
| Coefficient linear expansion | 1.9×10-5/℃ | 1.8×10-5/℃ | 1.6×10-5/℃ | 1.8×10-5/℃ | 1.9×10-5/℃ |
| Max. Temp. | -40~+300℃ | -40~+400℃ | -40~+400℃ | -40~+400℃ | -40~+300℃ |
| Max. dynamic load | 100 | 60 | 50 | 70 | 120 |
| Max. speed(Dry) | 15 | 10 | 20 | 10 | 15 |
| N/mm²*m/s(Lubrication) | 200 | 60 | 60 | 80 | 200 |
| Compression deformation | < 0.01 mm | < 0.05mm | < 0.04mm | < 0.05mm | < 0.005mm |
Customized Bronze Plates: Tailored Precision for Your Industry We Craft Personalized Bronze Slide Plates to Suit Your Unique Specifications. Precision-Machined Bronze Plates BRONZE – GRAPHITE PLATE SPECIALIST
The bronze slide plate, a quintessential plain bearing, is extensively utilized across various sectors including industrial and automotive accessories. Leveraging our advanced in-house machining capabilities, we deliver superior quality bronze slide plates in a variety of compositions: Bronze with Graphite, Graphite-free Bronze, Greased Bronze, and grooved friction bronze guide bushings. Each is meticulously crafted to align with the bespoke needs of our clientele.
Our low-maintenance sliding components are integral to the construction of machinery and tools, designed to facilitate parts that undergo linear or rotary motion.
For the foundational design of a slide bronze plate, we extend engineering and design consultancy to refine the mold injection process and recommend the optimal material selection for your application.
We then initiate rapid prototyping to validate the feasibility and alignment with your requirements.
Post-approval, we fabricate the mold tooling and manufacture the component in our cutting-edge facility. We complement this with finishing services, including laser engraving and ultrasonic welding, ensuring each slide bronze plate meets stringent specifications.
Seeking further assistance? We can assemble your slide bronze plates, package them, and dispatch them directly to you. Our in-house tool shop stands ready to perform necessary repairs or preventive maintenance on your slide bronze plates.
Employing precision equipment, we maintain strict dimensional controls and uphold tight tolerances, a hallmark of industries that demand exactitude.
We expedite the delivery of manufactured slide bronze plate parts, ensuring swift project realization.
Transform your vision into reality with our specialized manufacturing services for slide bronze plates, encompassing custom injection molding, CNC production machining, and tooling. Our comprehensive support extends to engineering, project management, assembly, kitting, and warehousing, streamlining your operations and enhancing supply chain efficiency.
Operating behind the scenes, we contribute to the creation of products and equipment that enhance daily life, with slide bronze plate parts that are indispensable in various applications, from oil and energy to everyday objects.
Our workflow is structured for efficiency and precision.
Bronze Graphite Plates & Bushings Expertise in Bronze Graphite Plates, offering a wealth of experience across diverse markets, from molds and oil and gas to healthcare. We cater to businesses of all scales, providing support from simple to complex bronze slide bearing plate parts. bronzelube.com is your reliable partner, guiding you from inception to completion.
V, T, and L Sharp Bronze Plates An Overview of Bronze Graphite Plates:
Bronze wear plates serve as linear bearings, guiding and controlling motion with precision. When these plates manage linear motion, they withstand significant force. We offer a spectrum of bronze wear plates, varying in sharpness and materials.
Self-lubricating bronze products are crafted through CNC machining, employing state-of-the-art milling machines, lathes, plasma cutting machines, CNC routers, and lasers, as well as pick-and-place CNC machines and 3D printers. These technologies are pivotal across automotive, millwork, plastic injection molding, and other manufacturing applications.
Contact us today to discuss your CNC machining slide plate production requirements!
Bronze wear strips, also known as bronze guide rails or bronze sliders, are a type of wear-resistant material commonly used in industrial machinery. They are typically employed in applications such as sliding bearings, guide rail systems, and other areas where low friction and high wear resistance are required. Bronze wear strips can include the following special features:
Size: Bronze wear strips can be customized to specific dimensions to fit various mechanical designs and application needs.
Shape: They can be manufactured in a variety of shapes, such as rectangular, circular, or other irregular forms, to meet the requirements of specific mechanical structures.
Holes: The bronze wear strips can be designed with holes for mounting or connecting with other components.
Hole Pattern: The arrangement of holes can be designed according to a specific pattern to accommodate particular installation requirements.
Pockets: Bronze wear strips can feature recesses or pockets to hold lubricants or other media.
Chamfers: The edges can be designed with chamfers to reduce friction and wear during installation.
Cutouts: The bronze wear strips can have cutouts for weight reduction or to provide additional mounting points.
These characteristics make bronze wear strips highly flexible and versatile in industrial applications, allowing for customization based on specific engineering requirements.
Bronze Plate Production Excellence: Your Comprehensive Manufacturing Partner Supplier of High-Quality Injection Molded and CNC-Machined Bronze Wear Plates Your go-to resource for the design and production of self-lubricating bearings, sliding components, wear plates, bronze plates, and related tooling across a multitude of industries.
Oil-Free Bronze Plates. Precision Bronze Castings. Linear Designs. Our solid lubricant-infused, graphite-impregnated wear plates, and custom-sized self-lubricating bronze wear plates are tailored to your specific application needs.
As a full-service product design and manufacturing entity, we excel in rapid prototyping, engineering, and comprehensive product development. We fabricate a diverse range of custom-engineered slide bronze plates from an assortment of materials, utilizing the latest automated plastic molding work cells and CNC machining technologies. We cater to industries such as defense, consumer goods, commerce, automotive, and recreational equipment, with our team of knowledgeable and seasoned professionals guiding each component or product from the conceptual phase through to production.
For your bronze plate manufacturing needs, don’t wait—reach out for a quote now!
